Double End Parallel Pins

Name: Double End Parallel Pins
Brand: Wenqi
SKU: 253292511

Double End Parallel Pins offer several advantages, particularly in precision assembly and alignment applications

Send Inquiry

Description

Double End Parallel Pins are precision alignment fasteners used to accurately position components in various mechanical assemblies. They have parallel or consistent diameter ends that extend outward from the pin's central body, and both ends are typically ground to ensure consistent dimensions and high tolerance.

Double End Parallel Pins

Size:

Can be customized

Material:

100Cr6, AISI52100, SUJ2

Tolerance:

Heat treatment:

Hardened and tempered to HRC 58~62

Coating:

Uncoated

Surface finish:

Plain

Our Product

Here's a breakdown of their main features and uses:

Parallel Diameter

The pin diameter remains consistent across its length, providing precise alignment capabilities. This helps maintain stability between assembled parts and prevents misalignment, which is critical in high-precision applications.

Double-End Design

Unlike regular dowel pins, Double End Parallel Pins have two identical ends, making them useful in applications where both ends of the pin will be engaged by parts needing alignment or positioning.

Standard Specifications

Double End Parallel Pins are typically manufactured to industry standards (like ISO or DIN), ensuring compatibility and reliability in engineering and manufacturing settings.

Would you like more details on specific dimensions or use cases, particularly for applications at Wenqi Machinery? Let me know if you'd like to explore more specific uses or standards.
